詳細信息
型號含義 Modelim plication
適用范圍 Applications
1.環境溫度-25°至55°。
2.安裝高度不超過海拔2000m。
3.多水、多塵、潮濕等環境，防弱酸、弱堿腐蝕。
4.廣泛應用于食品、制藥、車站、加油站、商場、大型廳堂等工廠企業及商品場所。
5.根據配置的鎮流器，必須選擇匹配的光源，用戶電源電壓波動范圍必須滿足國家標準要求。
1.Ambient temperature is-25°to 55°.
2.The height of installment can't over 2000 meters above sea level.
3.They can withstand the corrosion of weak acid, weak alkali and the environment of more water, more dust and humidity.
4.They are widely used in the lines of petroleum, chemistry, hell, food. Medicine, industrial and commercial concourse andso on.
5.According to suited ballast, they must choose illumination accordingly. The user's power voltage fluctuant range must accordto the national standard.
產品特點 Features
1.方形鋁合金外殼，采用高強度鋁合金一次性壓鑄成型，表面高速拋丸高壓靜電噴塑，外形美觀且防腐性能好；
2.鋼化玻璃,透光性好，不銹鋼外露堅固件；
3.燈具與鎮流器等附件為一體式設計，光源腔與鎮流器腔分別獨立，采用側面開蓋，快速更換燈泡，便于安裝維修；
4.反光罩經過專業二次配光設計，并得到實際應用驗證。使用桔紋漫反射板可使光線柔和，照射角幅度大；可加裝補償電容，補償后CosФ≥0.8；
5.電纜布線。
1.The quadrate enclosure is made of aluminum alloy. It is moulded by the high strength aluminum alloy for one time, whichhas high strength, fine explosion-proof functions. Its exterior has sprayed with plastic by high pressure static after shotblasting at high speed.
2.Lamp housing is made of high borosilicate glass with great transmittance. Outer fasteners are made of stainless steel.
3.Lamp and ballast are designed holistically. However, the light cavity and ballast are independent. We should open thecover in flank to replace the bulb immediately. And it's convenient to install and maintain.
4.The reflect should get special software design of distribution for two times, and it can have the confirmation of acgtualtest. Using orange-peel diffuse plate to make the light soft and make the irradiation range large. It can be also added thecompensation capacitor CosФ≥0.8.
5 Wiring with cables.
主要技術參數 Main technical parameters
1.執行標準：GB7000.1-2007
2.安裝形式：吸頂式(X)、支架式(B)、路燈式(詳見P108);
3.配光曲線：見后圖。
1.Accord with the standard for GB7001.1-2007;
2.Installation: ceiling type(X), bracket type(G),type of street lamp(detailedon page 108).
3.Luminous distribution curve can be seen from next page.
外形及安裝尺寸 Outline & installation dimensions
